• Material: high-modulus carbon fiber
• Perfil: 90/95mm
• Ancho exterior: 28mm
• Ancho interior: 21mm
• Tamaño: 700c
• Profile: Wave
• Peso Tier: Standard
• PSI máximo: 110 psi

• Aero vs Crosswind: Deep 90/95mm profile offers excellent aerodynamic efficiency but can be challenging in strong crosswinds; wave design mitigates but not fully. The 28mm external width helps stability, but crosswinds above 30km/h require attention.
• Peso vs Durability: At 615g±15g, it is light for its Perfil, but the high-modulus carbon is less forgiving on impacts than alloy. Prioritizes stiffness and aero over impact toughness, so avoiding potholes is advised.
• Tire Volume vs Speed: 21mm internal width supports 25-32mm tires; wider tires (28-32mm) improve comfort and grip but may have higher rolling resistance than 25mm. Optimal 28mm balances speed and comfort on varied surfaces.
• Price vs Performance: Premium high-modulus carbon and Tubeless-ready construction command a higher price, but the aero gains and Peso savings justify it for competitive TT and triathlon use.

• Fatigue Test: 750,000 cycles @640N (ISO 4210-7 Annex A, informative only)
• Impact Resistance: >40J (ISO 4210-7 reference)
• Flatness: <0.25mm (internal QC)
• Roundness: <0.3mm (internal QC)
• Max Radio Tension: >300kg (internal QC)
• Ultimate Strength: >100kg (internal QC)
• Dynamic Equilibrium: <3g (internal QC)
• Radial Stiffness: 90–110 N/mm (internal lab)
• Lateral Stiffness: ≥8N/mm
• Max System Peso: 125

• Sprinting / Criterium: Good. The deep rim provides aero benefits on fast, flat circuits, but the 615g Peso and crosswind sensitivity make it less nimble in tight corners.
• Triathlon / TT: Excellent. Designed for time trials and triathlons, the 90/95mm Perfil and Tubeless compatibility offer maximum aero efficiency and speed.
• Road Racing: Good. Suitable for flat to rolling races where aero gains outweigh Peso penalty; not ideal for hilly routes.
• Gran Fondo / Endurance: Suitable. The 28mm external width and ability to run 28mm tires provide comfort, but crosswind handling may be tiring on long rides.
• Climbing / Hill Repeats: Not recommended. The 615g rim and deep profile are heavy and less efficient on steep grades.
• Not Recommended For: Technical descents, heavy crosswinds, and steep climbs.

• Frame Compatibility: 700C (ISO 622) - fits most road, TT, and triathlon frames with appropriate clearance
• Tire Type: Tubeless ready (hooked bead) and clincher
• Tire Width Range: 25-32mm (optimal 28mm)
• Freno Standard: Disc Freno (centerlock or 6-bolt)
• Drivetrain: Compatible with Shimano, SRAM, and Campagnolo via correct Cuerpo de rueda libre body
• Rotor Standard: Disc Freno Rotor (centerlock or 6-bolt)

Is this rim tubeless-ready?

Yes, it features a hooked tubeless bead (ETRTO standard) and is designed for tubeless tires. It supports pressures between 100-125 psi, ensuring a secure and airtight seal. The hooked bead reduces the risk of tire burping during high-pressure efforts.

What tire widths can I use with this rim?

The 21mm internal width accommodates tires from 25mm to 32mm. The optimal width is 28mm, which balances rolling resistance, grip, and comfort. It is also compatible with clincher tires, offering versatility.

How much weight can I save compared to a standard alloy rim?

This carbon rim weighs approximately 615g±15g, which is significantly lighter than a typical alloy aero rim of similar depth (often 800g+). This weight saving contributes to lower rotational mass and faster acceleration.

Can I build a custom wheelset with this rim?

Absolutely. This rim is designed for custom builds. You can pair it with your choice of hubs and spokes. It supports spoke tensions above 300kg, so it is compatible with high-quality hubs and spokes for a durable and stiff wheelset.

How do I maintain and inspect this rim?

Regularly inspect the rim for cracks, delamination, or impact damage, especially after hard rides. Check spoke tension and true the wheel as needed. Avoid excessive brake heat if using rim brakes (this is a disc-brake rim). Store in a cool, dry place and use carbon-safe cleaning products.
