• Material: T700/T800 carbon
• Rim depth: 40mm
• External width: 28/30/32mm
• Internal width: 21/24/26mm
• Size: 700c
• Hub: BL300 CNC 54T
• Bearing: Enduro Steel
• Spoke: P1423 24/24 2X SP
• Wheelset weight (+/-2% tolerance, excluding rim tape and valves): 1370g

• Aero vs Climbing: The 40mm rim depth provides a good aero balance, while the 1360g weight keeps it light enough for climbing. This makes it a versatile choice for hilly races and flat time trials.
• Stiffness vs Compliance: The carbon layup offers high stiffness for efficient power transfer, but the tubeless setup allows pressures as low as 60psi to enhance ride comfort without losing much speed.
• Tire Volume vs Speed: You can run tires from 25mm to 45mm wide, but narrower tires (25-28mm) will yield lower rolling resistance, while wider (35-40mm) provide more grip and compliance for gravel.
• Price vs Grade: This wheelset retails for significantly less than premium carbon options (around $1,200 vs $2,000+), making it an excellent value for the performance and ISO4210 safety certification.

• Fatigue Test: 750,000 cycles @640N (ISO 4210-7 Annex A, informative only)
• Impact Resistance: >40J (ISO 4210-7 reference)
• Flatness: <0.25mm (internal QC)
• Roundness: <0.3mm (internal QC)
• Max Spoke Tension: >300kg (internal QC)
• Ultimate Strength: >100kg (internal QC)
• Dynamic Equilibrium: <3g (internal QC)
• Radial Stiffness: 90–110 N/mm (internal lab)
• Lateral Stiffness: 38-48 N/mm
• Max System Weight: 105kg (rider+bike+gear)

• Climbing / Hill Repeats: Good
• Gran Fondo / Endurance: Excellent
• Road Racing: Good
• Sprinting / Criterium: Good
• Training / Daily Riding: Excellent
• Not Recommended For: Not recommended

• Frame Compatibility: Road or gravel bikes with disc brakes and 700C wheels, designed for 12x100mm front and 12x142mm rear through-axles.
• Tire Type: Tubeless clincher (tubeless-ready) or with inner tubes.
• Tire Width Range: 25mm - 50mm
• Brake Standard: Disc brake (center-lock rotor interface)
• Axle Standard: 12x100mm(F)/12x142mm(R)
• Drivetrain: Shimano/SRAM 11-speed (freehub)
• Rotor Standard: Center-lock (rotors not included)

Is this wheelset suitable for gravel riding?

Yes, the 40mm depth and tubeless-ready design make it versatile for both road and gravel. With a wide tire clearance (up to 45mm), you can run aggressive treads for mixed terrain while enjoying low pressures for comfort and traction.

What tire pressure should I run?

For road use, start around 80-90 psi for 25mm tires. For gravel, lower to 35-45 psi for 40mm tires. Tubeless setups allow lower pressures without pinch flats, improving comfort and grip.

Is the hub engagement suitable for climbing and sprinting?

The hub features a 54-tooth ratchet with 6.7 degrees of engagement, providing quick acceleration response. This is ideal for technical sections and sprinting.

Can I upgrade to these wheels without changing my bike?

The wheelset fits standard 12x100mm front and 12x142mm rear through-axles, which are common on modern disc brake road and gravel bikes. Ensure your frame and fork are compatible with disc brakes.

What is the weight limit for this wheelset?

The wheelset is rated for a system weight of 120kg (rider plus bike). For riders above this, we recommend consulting our technical team for tailored advice.

• Warranty Period: 3 years for rims / 2 years for wheelsets
• Warranty Coverage: Manufacturing defects on carbon structure
• Crash Replacement: 30% discount within warranty period
• Processing Time: 1–3 business days; 7–15 business days for custom or out-of-stock items
• Shipping Method: FedEx / UPS / DPD Economy (free, duties & VAT included in USA & EU) · Expedited option at checkout (duties & VAT payable on delivery)
• Estimated Delivery:Economy 7–20 business days · Expedited 3–7 business days, excluding customs clearance
• Packaging: Double-wall carton with foam protection
